Workspace for solving multidimensional root finding problems. More...

#include <multiroots.hpp>

Collaboration diagram for gsl::multiroot::fdfsolver:

Public Types
typedef gsl_multiroot_fdfsolver_type	type
	Typedef. More...

Public Member Functions
	fdfsolver ()
	The default constructor is only really useful for assigning to. More...

	fdfsolver (type const *T, size_t const n)
	The default constructor creates a new fdfsolver with n elements. More...

	fdfsolver (gsl_multiroot_fdfsolver *v)
	Could construct from a gsl_multiroot_fdfsolver. More...

	fdfsolver (fdfsolver const &v)
	The copy constructor. More...

fdfsolver &	operator= (fdfsolver const &v)
	The assignment operator. More...

	~fdfsolver ()
	The destructor only deletes the pointers if count reaches zero. More...

	fdfsolver (fdfsolver &&v)
	Move constructor. More...

fdfsolver &	operator= (fdfsolver &&v)
	Move operator. More...

bool	operator== (fdfsolver const &v) const
	Two fdfsolver are identically equal if their elements are identical. More...

bool	operator!= (fdfsolver const &v) const
	Two fdfsolver are different if their elements are not identical. More...

bool	operator< (fdfsolver const &v) const
	A container needs to define an ordering for sorting. More...

bool	operator> (fdfsolver const &v) const
	A container needs to define an ordering for sorting. More...

bool	operator<= (fdfsolver const &v) const
	A container needs to define an ordering for sorting. More...

bool	operator>= (fdfsolver const &v) const
	A container needs to define an ordering for sorting. More...

bool	empty () const
	Find if the fdfsolver is empty. More...

void	swap (fdfsolver &v)
	Swap two fdfsolver objects. More...

gsl_multiroot_fdfsolver *	get () const
	Get the gsl_multiroot_fdfsolver. More...

bool	unique () const
	Find if this is the only object sharing the gsl_multiroot_fdfsolver. More...

size_t	use_count () const
	Find how many fdfsolver objects share this pointer. More...

	operator bool () const
	Allow conversion to bool. More...

int	set (function_fdf &f, vector const &x)
	C++ version of gsl_multiroot_fdfsolver_set(). More...

int	iterate ()
	C++ version of gsl_multiroot_fdfsolver_iterate(). More...

char const *	name ()
	C++ version of gsl_multiroot_fdfsolver_name(). More...

vector const	root ()
	C++ version of gsl_multiroot_fdfsolver_root(). More...

vector const	dx ()
	C++ version of gsl_multiroot_fdfsolver_dx(). More...

vector const	f ()
	C++ version of gsl_multiroot_fdfsolver_f(). More...

Static Public Member Functions
static int	set (fdfsolver &s, function_fdf &f, vector const &x)
	C++ version of gsl_multiroot_fdfsolver_set(). More...

static int	iterate (fdfsolver &s)
	C++ version of gsl_multiroot_fdfsolver_iterate(). More...

static std::string	name (fdfsolver const &s)
	C++ version of gsl_multiroot_fdfsolver_name(). More...

static vector	root (fdfsolver const &s)
	C++ version of gsl_multiroot_fdfsolver_root(). More...

static vector	dx (fdfsolver const &s)
	C++ version of gsl_multiroot_fdfsolver_dx(). More...

static vector	f (fdfsolver const &s)
	C++ version of gsl_multiroot_fdfsolver_f(). More...

static type const *	hybridsj ()
	Static type. More...

static type const *	hybridj ()
	Static type. More...

static type const *	newton ()
	Static type. More...

static type const *	gnewton ()
	Static type. More...

Private Attributes
gsl_multiroot_fdfsolver *	ccgsl_pointer
	The shared pointer. More...

size_t *	count
	The shared reference count. More...

Detailed Description

Workspace for solving multidimensional root finding problems.

Also functions as a namespace for fdfsolver functions. This also allows for functions to be called on fdfsolver as an object.

Definition at line 438 of file multiroots.hpp.

Member Typedef Documentation

◆ type

typedef gsl_multiroot_fdfsolver_type gsl::multiroot::fdfsolver::type

Typedef.

Definition at line 443 of file multiroots.hpp.

Constructor & Destructor Documentation

◆ fdfsolver() [1/5]

gsl::multiroot::fdfsolver::fdfsolver ( )

inline

The default constructor is only really useful for assigning to.

Definition at line 447 of file multiroots.hpp.

◆ fdfsolver() [2/5]

gsl::multiroot::fdfsolver::fdfsolver	(	type const *	T,
		size_t const	n
	)

inlineexplicit

The default constructor creates a new fdfsolver with n elements.

Parameters

T	The fdfsolver type.
n	The number of elements in the fdfsolver.

Definition at line 458 of file multiroots.hpp.

References gsl::rstat::n().

◆ fdfsolver() [3/5]

gsl::multiroot::fdfsolver::fdfsolver ( gsl_multiroot_fdfsolver * v )

inlineexplicit

Could construct from a gsl_multiroot_fdfsolver.

This is not usually a good idea. In this case we should not use gsl_multiroot_fdfsolver_free() to deallocate the memory.

Parameters

v	The fdfsolver

Definition at line 474 of file multiroots.hpp.

◆ fdfsolver() [4/5]

gsl::multiroot::fdfsolver::fdfsolver ( fdfsolver const & v )

inline

The copy constructor.

This creates a new reference to the workspace.

Parameters

v	The fdfsolver to copy.

Definition at line 485 of file multiroots.hpp.

References ccgsl_pointer, and count.

◆ ~fdfsolver()

gsl::multiroot::fdfsolver::~fdfsolver ( )

inline

The destructor only deletes the pointers if count reaches zero.

Definition at line 504 of file multiroots.hpp.

◆ fdfsolver() [5/5]

gsl::multiroot::fdfsolver::fdfsolver ( fdfsolver && v )

inline

Move constructor.

Parameters

v	The fdfsolver to move.

Definition at line 516 of file multiroots.hpp.

Member Function Documentation

◆ dx() [1/2]

vector const gsl::multiroot::fdfsolver::dx ( )

inline

C++ version of gsl_multiroot_fdfsolver_dx().

Note that it is this fdfsolver and not the return value that owns the data in the return value.

Returns: The last step taken by the solver.

Definition at line 766 of file multiroots.hpp.

References gsl::rstat::quantile::get().

◆ dx() [2/2]

static vector gsl::multiroot::fdfsolver::dx ( fdfsolver const & s )

inlinestatic

C++ version of gsl_multiroot_fdfsolver_dx().

Note that it is s and not the return value that owns the data in the return value.

Parameters

s	The fdfsolver.

Returns: The last step taken by the solver.

Definition at line 697 of file multiroots.hpp.

References get().

◆ empty()

bool gsl::multiroot::fdfsolver::empty ( ) const

inline

Find if the fdfsolver is empty.

Returns: true if has size zero; otherwise false

Definition at line 593 of file multiroots.hpp.

◆ f() [1/2]

vector const gsl::multiroot::fdfsolver::f ( )

inline

C++ version of gsl_multiroot_fdfsolver_f().

Note that it is this fdfsolver and not the return value that owns the data in the return value.

Returns: The function value at the current estimate of the root.

Definition at line 778 of file multiroots.hpp.

References gsl::rstat::quantile::get().

◆ f() [2/2]

static vector gsl::multiroot::fdfsolver::f ( fdfsolver const & s )

inlinestatic

C++ version of gsl_multiroot_fdfsolver_f().

Note that it is s and not the return value that owns the data in the return value.

Parameters

s	The fdfsolver.

Returns: The function value at the current estimate of the root.

Definition at line 709 of file multiroots.hpp.

References get().

◆ get()

gsl_multiroot_fdfsolver * gsl::multiroot::fdfsolver::get ( ) const

inline

Get the gsl_multiroot_fdfsolver.

Returns: the gsl_multiroot_fdfsolver

Definition at line 619 of file multiroots.hpp.

Referenced by dx(), f(), iterate(), name(), and root().

◆ gnewton()

static type const * gsl::multiroot::fdfsolver::gnewton ( )

inlinestatic

Static type.

Returns: the named fdfsolver type

Definition at line 804 of file multiroots.hpp.

◆ hybridj()

static type const * gsl::multiroot::fdfsolver::hybridj ( )

inlinestatic

Static type.

Returns: the named fdfsolver type

Definition at line 794 of file multiroots.hpp.

◆ hybridsj()

static type const * gsl::multiroot::fdfsolver::hybridsj ( )

inlinestatic

Static type.

Returns: the named fdfsolver type

Definition at line 789 of file multiroots.hpp.

◆ iterate() [1/2]

int gsl::multiroot::fdfsolver::iterate ( )

inline

C++ version of gsl_multiroot_fdfsolver_iterate().

Returns: Error code on failure.

Definition at line 739 of file multiroots.hpp.

References gsl::rstat::quantile::get().

◆ iterate() [2/2]

static int gsl::multiroot::fdfsolver::iterate ( fdfsolver & s )

inlinestatic

C++ version of gsl_multiroot_fdfsolver_iterate().

Parameters

s	The fdfsolver.

Returns: Error code on failure.

Definition at line 667 of file multiroots.hpp.

References get().

◆ name() [1/2]

char const * gsl::multiroot::fdfsolver::name ( )

inline

C++ version of gsl_multiroot_fdfsolver_name().

Returns: The name of the solver.

Definition at line 746 of file multiroots.hpp.

References gsl::rstat::quantile::get().

◆ name() [2/2]

static std::string gsl::multiroot::fdfsolver::name ( fdfsolver const & s )

inlinestatic

C++ version of gsl_multiroot_fdfsolver_name().

Parameters

s	The fdfsolver.

Returns: The name of the solver.

Definition at line 675 of file multiroots.hpp.

References get().

◆ newton()

static type const * gsl::multiroot::fdfsolver::newton ( )

inlinestatic

Static type.

Returns: the named fdfsolver type

Definition at line 799 of file multiroots.hpp.

◆ operator bool()

gsl::multiroot::fdfsolver::operator bool ( ) const

inlineexplicit

Allow conversion to bool.

Returns: true or false according as this contains a pointer to a gsl_multiroot_fdfsolver.

Definition at line 639 of file multiroots.hpp.

◆ operator!=()

bool gsl::multiroot::fdfsolver::operator!= ( fdfsolver const & v ) const

inline

Two fdfsolver are different if their elements are not identical.

Parameters

v	The fdfsolver to be compared with `this`

Returns: false or true according as this and v have identical elements or not

Definition at line 546 of file multiroots.hpp.

◆ operator<()

bool gsl::multiroot::fdfsolver::operator< ( fdfsolver const & v ) const

inline

A container needs to define an ordering for sorting.

This uses standard lexicographical ordering and so is not useful, for example, for checking, that a fdfsolver is nonnegative.

Parameters

v	The fdfsolver to be compared with `this`

Returns: false or true according as this is less than v lexicographically

Definition at line 558 of file multiroots.hpp.

References ccgsl_pointer.

◆ operator<=()

bool gsl::multiroot::fdfsolver::operator<= ( fdfsolver const & v ) const

inline

A container needs to define an ordering for sorting.

This uses standard lexicographical ordering and so is not useful, for example, for checking, that a fdfsolver is nonnegative.

Parameters

v	The fdfsolver to be compared with `this`

Returns: false or true according as this is less than or equal to v lexicographically

Definition at line 578 of file multiroots.hpp.

References ccgsl_pointer.

◆ operator=() [1/2]

fdfsolver & gsl::multiroot::fdfsolver::operator= ( fdfsolver && v )

inline

Move operator.

Parameters

v	The fdfsolver to move.

Returns: A reference to this.

Definition at line 525 of file multiroots.hpp.

References swap().

◆ operator=() [2/2]

fdfsolver & gsl::multiroot::fdfsolver::operator= ( fdfsolver const & v )

inline

The assignment operator.

This copies elementwise.

Parameters

v	The fdfsolver to copy

Definition at line 492 of file multiroots.hpp.

References ccgsl_pointer, and count.

◆ operator==()

bool gsl::multiroot::fdfsolver::operator== ( fdfsolver const & v ) const

inline

Two fdfsolver are identically equal if their elements are identical.

Parameters

v	The fdfsolver to be compared with `this`

Returns: true or false according as this and v have identical elements or not

Definition at line 538 of file multiroots.hpp.

References ccgsl_pointer.

◆ operator>()

bool gsl::multiroot::fdfsolver::operator> ( fdfsolver const & v ) const

inline

A container needs to define an ordering for sorting.

This uses standard lexicographical ordering and so is not useful, for example, for checking, that a fdfsolver is nonnegative.

Parameters

v	The fdfsolver to be compared with `this`

Returns: false or true according as this is greater than v lexicographically

Definition at line 568 of file multiroots.hpp.

References ccgsl_pointer.

◆ operator>=()

bool gsl::multiroot::fdfsolver::operator>= ( fdfsolver const & v ) const

inline

A container needs to define an ordering for sorting.

This uses standard lexicographical ordering and so is not useful, for example, for checking, that a fdfsolver is nonnegative.

Parameters

v	The fdfsolver to be compared with `this`

Returns: false or true according as this is no less than v lexicographically

Definition at line 588 of file multiroots.hpp.

References ccgsl_pointer.

◆ root() [1/2]

vector const gsl::multiroot::fdfsolver::root ( )

inline

C++ version of gsl_multiroot_fdfsolver_root().

Note that it is this fdfsolver and not the return value that owns the data in the return value.

Returns: The current estimate of the root.

Definition at line 754 of file multiroots.hpp.

References gsl::rstat::quantile::get().

◆ root() [2/2]

static vector gsl::multiroot::fdfsolver::root ( fdfsolver const & s )

inlinestatic

C++ version of gsl_multiroot_fdfsolver_root().

Note that it is s and not the return value that owns the data in the return value.

Parameters

s	The fdfsolver.

Returns: The current estimate of the root.

Definition at line 685 of file multiroots.hpp.

References get().

◆ set() [1/2]

static int gsl::multiroot::fdfsolver::set	(	fdfsolver &	s,
		function_fdf &	f,
		vector const &	x
	)

inlinestatic

C++ version of gsl_multiroot_fdfsolver_set().

Parameters

s	The fdfsolver.
f	The function.
x	The initial guess of the root.

Returns: Error code on failure.

Definition at line 659 of file multiroots.hpp.

◆ set() [2/2]

int gsl::multiroot::fdfsolver::set	(	function_fdf &	f,
		vector const &	x
	)

inline

C++ version of gsl_multiroot_fdfsolver_set().

Parameters

f	The function.
x	The initial guess of the root.

Returns: Error code on failure.

Definition at line 732 of file multiroots.hpp.

◆ swap()

void gsl::multiroot::fdfsolver::swap ( fdfsolver & v )

inline

Swap two fdfsolver objects.

This works even if the fdfsolver have different sizes because it swaps pointers.

Parameters

v	The fdfsolver to swap with `this`.

Definition at line 600 of file multiroots.hpp.

References ccgsl_pointer, and count.

Referenced by operator=().

◆ unique()

bool gsl::multiroot::fdfsolver::unique ( ) const

inline

Find if this is the only object sharing the gsl_multiroot_fdfsolver.

Returns: true or falses according as this is the only workspace object sharing the gsl_multiroot_fdfsolver.

Definition at line 625 of file multiroots.hpp.

◆ use_count()

size_t gsl::multiroot::fdfsolver::use_count ( ) const

inline

Find how many fdfsolver objects share this pointer.

Returns: the number of workspace objects that share this pointer.

Definition at line 630 of file multiroots.hpp.

Member Data Documentation

◆ ccgsl_pointer

gsl_multiroot_fdfsolver* gsl::multiroot::fdfsolver::ccgsl_pointer

private

The shared pointer.

Definition at line 608 of file multiroots.hpp.

Referenced by fdfsolver(), operator<(), operator<=(), operator=(), operator==(), operator>(), operator>=(), and swap().

◆ count

size_t* gsl::multiroot::fdfsolver::count

private

The shared reference count.

Definition at line 612 of file multiroots.hpp.

Referenced by fdfsolver(), operator=(), and swap().

The documentation for this class was generated from the following file:

multiroots.hpp

Public Types

Public Member Functions

Static Public Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

◆ type

Constructor & Destructor Documentation

◆ fdfsolver() [1/5]

◆ fdfsolver() [2/5]

◆ fdfsolver() [3/5]

◆ fdfsolver() [4/5]

◆ ~fdfsolver()

◆ fdfsolver() [5/5]

Member Function Documentation

◆ dx() [1/2]

◆ dx() [2/2]

◆ empty()

◆ f() [1/2]

◆ f() [2/2]

◆ get()

◆ gnewton()

◆ hybridj()

◆ hybridsj()

◆ iterate() [1/2]

◆ iterate() [2/2]

◆ name() [1/2]

◆ name() [2/2]

◆ newton()

◆ operator bool()

◆ operator!=()

◆ operator<()

◆ operator<=()

◆ operator=() [1/2]

◆ operator=() [2/2]

◆ operator==()

◆ operator>()

◆ operator>=()

◆ root() [1/2]

◆ root() [2/2]

◆ set() [1/2]

◆ set() [2/2]

◆ swap()

◆ unique()

◆ use_count()

Member Data Documentation

◆ ccgsl_pointer

◆ count
